Ultra-Low Frequency High Voltage 60kV VLF Cable Testing Equipment
1. Specifications
| Model | Rated Voltage | Load Capacity | Fuse | Weight | Application |
| VLF-60kV | 60kV (Peak) | 0.1Hz,≤0.5µF 0.05Hz,≤1.0µF 0.02Hz,≤2.5µF 0.01Hz,≤5.0µF | 25A | Control : 6KG HV TANK I: 30KG HV TANK II: 50KG | 25KV and below the cable,Generator |
| Use HV TANK I alone | 30kV (Peak) | 0.1Hz,≤1.1µF 0.05Hz,≤2.2µF 0.02Hz,≤5.5µF 0.01Hz,≤11.0µF | 10KV and below the cable,Generator |
2. Main Features
Data of current and voltage are obtained directly through the sampling of high-pressure side and it is true and accurate.
Over-voltage protection.
Over-current protection.
High-voltage output protection resistor design in the HV TANK and it is no need to additional outside resistor.
Closed-loop negative feedback control circuit of high and low voltage.
3. How to choose the suitable products for test
Please make sure that the capacitance of test products is below the instrument rated capacitance . The waveform will be influence if the capacitance of test products is too small and the instrument can not normally output when it below 0.05µF. 0.05µF capacitor in parallel to auxiliary output . Below is capacitance of some instrument for your reference .
Single relatively power capacity of different Generator
| Thermal Power | Hydropower | ||||||
Generator capacitance (MW) | 200 | 300 | 600 | 85 | 125-150 | 300 | 400 |
| Single relatively power capacity (µF) | 0.2-0.25 | 0.18-0.26 | 0.31-0.34 | 0.69 | 1.8-1.9 | 1.7-2.5 | 2.0-2.5 |
Power capacitance of single-core XLPE insulated cable (µF/km)
| Capacity µF/Km | ||||||||||||
| Voltage (kV) | 10 | 0.15 | 0.17 | 0.18 | 0.19 | 0.21 | 0.24 | 0.26 | 0.28 | 0.32 | 0.38 | - |
| 35 | - | - | - | 0.11 | 0.12 | 0.13 | 0.14 | 0.15 | 0.16 | 0.17 | 0.19 | |
| Cross-sectional area (mm2 ) | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 | 185 | 240 | 270 | |
4. Different Rated Voltage for choice
